Digital Projection Titan Quad / 800 / 930 Series ASPECT RATIOS EXPLAINED Reference Guide

139

Rev H October 2013

Aspect ratio examples for DMD™ resolution 1080p (continued)

Source: 16:10

Unused screen areas

Cropped parts of the image

Notes

Aspect Ratio: Fill Display

Aspect Ratio: Source

Aspect Ratio: Fill & Crop
