Digital Projection Titan Quad / 800 / 930 Series APPENDIX C: SUPPORTED SIGNAL INPUT MODES Reference Guide
171
Rev H October 2013
Standard
Resolution
Vertical Frequency
(Hz)
Total number of lines
Horizontal
Frequency (kHz)
Composite 1 & 2 /
S-Video
Component
DVI-A / VGA
DVI-D / HDMI
3G-SDI
HDTV continued 1080i60 1920 x 1080 60.00 1125 33.75
  
1080p60 1920 x 1080 60.00 1125 67.50
  
COMPUTER VGA59 640 x 480 59.94 525 31.47
 
VGA60 640 x 480 60.00 525 31.50
 
MACI 640 x 480 66.67 525 35.00
 
VGA72 640 x 480 72.81 520 37.86
 
VGA75 640 x 480 75.00 500 37.50
 
DOS70 720 x 400 70.09 449 31.47
 
SVGA50 800 x 600 49.92 621 31.00
 
SVGA56 800 x 600 56.25 625 35.16
 
SVGA60 800 x 600 60.32 628 37.88
 
SVGA72 800 x 600 72.19 666 48.08
 
SVGA75 800 x 600 75.00 625 46.88
 
MACII 832 x 624 75.08 1120 49.10
 
XGA50 1024 x 768 49.98 793 39.63
 
XGA60 1024 x 768 60.00 806 48.36
 
XGA70 1024 x 768 70.07 806 56.48
 
XGA75 1024 x 768 75.03 800 60.02
 
XGA+70 1152 x 864 70.01 912 63.85

XGA+75 1152 x 864 75.00 900 67.50

MAC2 1152 x 870 75.06 915 68.68
 
SUN1166 1152 x 900 66.00 937 61.85
 
