24
EN
IP2163EN
7.7.1 Additional RO level parameters that can be configured
(available with → enabled)
Display Description
C1, C2, C3, C4 - Selection of CH1, CH2, CH3, CH4 func-
tion of stored remote control.
NO - No setting selected
1-3 - Opening command
1-4 - Closing command
1-5 - Step-by-step command
P3 - Partial opening command
LG - Command to switch on/off the courtesy light
1-9 - STOP command
If only one (any) CH key of the remote control is stored,
the opening or step-by-step command is carried out.
WARNING: options
(opening) and (step-by-
step) are available as an alternative and depend on
the selection → .
If 2-4 CH keys of a single remote control are stored, the fac-
tory-set functions matched with the CH keys are as follows:
• CH1 = opening/step-by-step command;
• CH2 = partial opening command;
• CH3 = command to switch on/off the courtesy light
• CH4 = STOP command.
ER - Cancelling a single remote control.
→→
2”
EA - Cancelling an entire memory.
→→
2” 2”
EC - Cancelling a single code.
(FOR FUTURE USE)
RE - Setting memory opening from remote control.
OF - Disabled
ON - Enabled. When enabled (ON), the remote program-
ming is activated.
To store new remote controls without using the control panel,
press the PRG key of an already stored GOL4 remote control for
5 seconds until the LED comes on (within the range of the receiv-
er) and press any one of the CH keys on the new remote control.
NOTE: make sure you do not accidentally memorise un-
wanted remote controls.
EP -Setting the coded area messages
If the possibility to receive coded messages is enabled, the control pan-
el will be compatible with remote controls of the “ENCRYPTED” type.
MS - Backward compatibility setting with older gen-
eration GOL4 remote controls.
NOTE: Firmware version 2.0.7 or later
OF - Compatibility with old generation GOL4 and new
ZEN remote controls.
ON
- Compatibility with ZEN series remote controls.
NOTE: MS= ON is recommended if only ZEN series re-
mote controls are used on the system.
RO - Radio operations
