Place arm on unit at center line of unit. Then rotate the arm -5° (while holding the unit) so you can
remove the two screws that hold the Lock Kick / Stop Block Assembly. The Arm is under spring load
so do not release. After removing Lock Kick / Stop Block Assembly allow the arm to gently rotate to
remove the spring load.
Reinstall the Lock Kick / Stop Block Assembly in the alternate location (180° from its original position).
2.0 OPERATOR INSTALLATION
