Pg. 43
HA9 Manual V. 1.3
1019956
Settings for double doors
* For “Double egress doors” these functions must be set separately for MASTER and
SLAVE as the arm systems as well as the air pressure may be different.
Locks on the MASTER and SLAVE doors must be connected to the control unit (HA9) on the
corresponding operator.
Inner and outer impulses can be connected to either MASTER or SLAVE HA9 or both.
The OPD is to be connected to the MASTER HA9 except for “Double egress”, where each
OPD must be connected to corresponding HA9.
Door leaf mounted sensors must always be connected to corresponding HA9.
Function
Settings on the
MASTER
SLAVE
Common
Program selection
X
Opening time
X
Closing time
X
Hold open time
X
Close / Continue to open when the door is obstructed
X
PAG On/Off
X
Level of Power assist
X
(X)*
Extended closing force
X
(X)*
OPD Impulse or Mat Logic Impulse
X
Selection of operating mode during operation on battery
power
X
Individual
Lock/Unlock signal voltage
X
X
Locked without/with power
X
X
Lock release Enable/Disable
X
X
Open Delay Time
X
X
Lock kick Enable/Disable
X
X
