4.13 Expansion Module (specifications and connections)
Power supply: 24V Vac/dc
Analog Inputs: 7 configurable
0÷1V, 0÷5V, 0÷10V,
0÷20mA, 4÷20mA, NTC, PTC, DI
Analog Outputs: 3 configurable
0÷10V ( or DO for relay)
Digital Inputs: 3 (free contacts)
Digital Output: 6 relay 5A 250V
Connection: 1 CANBus
Address: Dip switch 4 positions
Can bitrate = 100Kbit/s
(set-up this value
through the browser
