1592025400 – Vers. 1.0 - 69 -
8.3.4 Exportation and Importation of FB
Through different ISaGRAF applications is possible to transfer the function blocks.
• Exportation
Select the function block to export (in this example ONOFF_Regulator).
Choose File Æ Export Æ POU
Select the directory to save the file (the extension of the file is .pxf).
When the process will be finished, choose close in the following window.
