1592025400 – Vers. 1.0 - 68 -
To complete the job, SAVE, COMPILE and EXECUTE your project.
The same program written with FBD language will be:
The considerations regarding the FB are:
• The description of regulator is immediate and complete.
• Every regulator is based on Function Block “ONOFF_Regulator”.
• Function block are made by everybody.
• Function blocks can have up to 128 outputs and inputs.
