13. THE VISOPROG WORKBENCH
13.1 Introduction
The VISOPROG workbench is the environment developed by Dixell to build the human
interface in the VISOGRAPH graphic lcd.
VISOPROG reads the ISaGRAF project from the iPRO and imports directly variables and
function blocks to create automatically the basic interface; then the developer completes the
interface adding functionality through the keys.
VISOPROG can import images and multi-languages dictionary.
13.2 The VISOPROG environment
The VISOPROG environment is composed by three areas:
• The STAGE area:
• The STAGE EDITOR area:
• The INFORMATION area (Object Properties, Main View, ...):
