dji INSPIRE 3 - Aircraft Landing Gears; Travel Mode Switching

DJI Inspire 3 User Manual
26
©
2023 DJI All Rights Reserved.
Entering Travel Mode: remove the gimbal camera with the aircraft powered on, press the power
button a minimum of ve times, wait for the aircraft to enter travel mode, and power o. Press
the battery release before removing a battery.
• After pressing the power button a minimum of five times with the gimbal camera
attached to the aircraft, the aircraft will enter travel mode once the gimbal camera is
removed. The aircraft cannot transform from landing mode to travel mode with the
gimbal camera attached.
• Keep your hands away from the transformation mechanism during the aircraft
transformation.
• For the situations that need to adjust the landing gear manually, insert the crossing-end
of the included screwdriver into the small hole on the bottom of the aircraft, and slowly
rotate the gear of the servo gearbox.
After the motor starts,
the front LEDs blink red and green alternately and the rear LEDs blink
green. The green lights indicate the aircraft is a UAV and the red lights indicate the heading and
position of the aircraft.
The Y-shaped LED is used to assist in indicating the direction of the aircraft rear. After the
aircraft is powered on, the Y-shaped LED will display solid green.
• Lighting requirements vary depending on the region. Observe local laws and
regulations.
Aircraft Landing Gears
The aircraft is in travel mode before delivery. Follow the steps below to transform it to landing
mode before rst use.
Travel Mode Switching
Place the aircraft on a at surface (such as a table) before switching between travel mode and
landing mode.
Unlocking Travel Mode: after mounting the batteries, press the power button a minimum of ve
times to transform the aircraft form travel mode to landing mode, and power on.
5
×
