Intelligent Battery Charging Hub
Charging Hub Overview
The DJI TB51 Intelligent Battery Charging Hub features eight TB51 battery ports and one USB-C
charging port. It can charge two TB51 batteries and one DJI RC Plus simultaneously.
1. System Status LED
2. Charging Port Status LEDs
3. Charging Mode Switch
4. USB-C Charging Port
5. TB51 Battery Port
6. Power Port
Warnings
• Keep liquids away from the inside of the charging hub.
• DO NOT block the air vent of the charging hub during charging. Make sure the vent is well-
ventilated and able to dissipate heat.
• The charging hub is only compatible with the TB51 battery. DO NOT use the charging hub
with any other battery models.
• Place the charging hub on a at and stable surface when in use. Make sure the device is
properly insulated to prevent re hazards.
• DO NOT attempt to touch the metal terminals on the battery port of the charging hub. Clean
the metal terminals with a clean, dry cloth if there is any noticeable buildup when powered
o.
• Carefully insert the battery after aligning the battery and the charging hub ports to avoid
battery damage.
• Keep your ngers away from the cover connection point when opening the charging hub to
avoid injury.
1
2
3
4
5
6
