dji INSPIRE 3 - DJI Three-Channel Follow Focus; DJI Master Wheels

DJI Inspire 3 User Manual
©
2023 DJI All Rights Reserved.
87
DJI Three-Channel Follow Focus
Mounting and Checking: mount the remote monitor with DJI Three-Channel Follow Focus, and
then power on the remote monitor.
Usage: use the focus knob on the DJI Three-Channel Follow Focus to control the focus of the X9-
8K Air camera lens.
• Read the DJI Master Wheels User Guide for more information.
• Read the DJI Three-Channel Follow Focus User Guide for more information.
DJI Master Wheels
Connection: mount the DJI Remote Monitor Expansion Plate to the remote monitor. Connect
any one of the DC-OUT port on DJI Master Wheels to the DC-IN port on the expansion plate
using the DJI High-Bright Remote Monitor Controller Cable.
Usage: once connected, use the wheels to control gimbal rotation.
