dji INSPIRE 3 - Mounting the Dongle; Using the Strap and Waist Support

DJI Inspire 3 User Manual
©
2023 DJI All Rights Reserved.
67
1. Push the rear cover release button to the end to open the rear cover. Remove the screws to
open the dongle compartment.
2. Insert the dongle into the USB-C connector. Close the dongle compartment.
3. Attach the dongle compartment with the screws. Close the rear cover.
Using the Strap and Waist Support
A strap can be mounted onto the waist support by following the steps below.
Mounting the Dongle
A Dongle (excluded) can be mounted onto the remote controller in the following steps.
1. Unfold the two handles.
2. Wear the strap, and attach the strap hooks to the handle holes.
3. Unfold the waist support.
• After use, hold the remote controller with one hand, unlock the strap hooks with the
other hand to remove the remote controller, and then take o the strap.
1
2
3
