Vision Systems and Infrared Sensing System
The aircraft is equipped with both an infrared sensing system and forward, backward, lateral,
upward, and downward vision systems.
The upward and downward vision systems consist of two cameras, and the forward, backward,
and lateral vision systems consist of four cameras in total.
The infrared sensing system consists of two infrared modules. The downward vision system and
infrared sensing system help the aircraft maintain its current position, hover more precisely,
and y indoors or in other environments where GNSS is unavailable.
In addition, the auxiliary bottom light located on the underside of the aircraft improves visibility
for the downward vision system in weak light conditions.
1. Horizontal Omnidirectional Vision
System
2. Upward Vision System
3. Downward Infrared Sensing
System
4. Downward Vision System
1 1
2
3
4
Detection Range
Forward Vision System
Precision Measurement Range: 1.5-48 m
Eective Sensing Speed: ≤15 m/s
FOV: 90° (horizontal, landing gears raised)
72° (horizontal, landing gears lowered), 103° (vertical)
Backward Vision System
Precision Measurement Range: 1.5-48 m
Eective Sensing Speed: ≤15 m/s
FOV: 90° (horizontal), 103° (vertical)
