dji INSPIRE 3 User Manual

DJI Inspire 3 User Manual
90
©
2023 DJI All Rights Reserved.
Scenario 3: using a remote controller, a video transmitter, a three-channel follow focus, and
multiple remote monitors. It is applied to 2-person or 3-person shooting, while the focus is
adjusted by the focus puller. It allows others to view the liveview from the third-party monitors
wirelessly or via wired connection.
The following solutions can also be selected for connecting with the remote monitor:
1. Left Hand Grip (gimbal control), Right Hand Grip (focus adjustment)
2. Three-Channel Follow Focus (focus adjustment)
3. Master Wheels (gimbal control)
O3 Pro
Broadcast Mode
HDMI/SDI
DJI High-Bright
Remote Monitor
Controller Cable

dji INSPIRE 3 Specifications

General

Camera Sensor	Full-Frame CMOS
Obstacle Sensing	Omnidirectional
Max Ascent Speed	8 m/s
Max Descent Speed	8 m/s
Internal Storage	1 TB SSD
Gimbal	3-axis (tilt, roll, pan)
Camera	Zenmuse X9-8K Air
Effective Pixels	24 MP
Gimbal Stabilization	±0.01°
Transmission System	DJI O3 Pro
Live View Quality	1080p/60fps
Remote Controller	DJI RC Plus
Remote Controller Charging Port	USB-C
Flight Time	28 minutes
Transmission Range	15 km
Max Speed	94 km/h
Operating Temperature	-20°C to 40°C
GNSS	GPS + Galileo + BeiDou
Operating Frequency	2.4000-2.4835 GHz; 5.725-5.850 GHz
Transmitter Power (EIRP)	2.4 GHz: <33 dBm; 5.8 GHz: <33 dBm
Hovering Accuracy Range	Vertical: ±0.1 m; Horizontal: ±0.3 m
ISO Range	Video: 100-25600
Shutter Speed	1/8000s to 2s
Supported File Formats	JPEG, DNG, MP4, MOV
Latency	90 ms
Remote Controller Operating Frequency	2.4000-2.4835 GHz; 5.725-5.850 GHz
Supported SD Cards	microSD
Video Resolution	8K
