28
©
2022 DJI All Rights Reserved.
MATRICE 30 SERIES User Manual
Calibrating the Compass
Only calibrate the compass when prompted to do so by the DJI Pilot 2 app or the aircraft rear
indicators. Observe the following rules when calibrating the compass:
DO NOT calibrate the compass in locations with strong magnetic interference, such as near
magnets, parking lots, or construction sites with underground reinforced concrete structures.
DO NOT carry ferromagnetic materials such as mobile phones during calibration.
The DJI Pilot 2 app will display a prompt if the compass is aected by strong interference after
calibration is complete. Follow the displayed instructions to resolve the compass issue.
Calibration Procedure
Perform the calibration in an open area and follow the steps below to complete the calibration.
1. Run the DJI Pilot 2 app and enter camera view on the homepage. Tap -> , then go to Sensor
Status, Compass, and Calibrate Compass to start the calibration. The aircraft rear indicators will glow
in solid yellow, which indicates that the calibration has started.
2. Hold the aircraft horizontally 1.5 m (4.92 ft) above the ground and rotate the aircraft 360 degrees.
The aircraft rear indicators will glow in solid green.
3. Hold the aircraft vertically with the nose pointing downward, and rotate the aircraft 360 degrees
around the center axis.
