61
©
2022 DJI All Rights Reserved.
MATRICE 30 SERIES User Manual
to open Shortcut Settings and turn on Silent mode to disable all voice alerts.
Any voice prompts and alerts will be disabled in Silent mode, including alerts during RTH and low
battery alerts for the remote controller or aircraft. Use with caution.
Charging the Remote Controller and Checking the Battery Level
Charging the Remote Controller
1. Connect the BS30 Intelligent Battery Station to a power outlet using the AC power adaptor cable.
2. Connect the battery station and the remote controller USB-C ports using a USB-C to USB-C cable.
3. The battery level LEDs start to ash to indicate that the Internal battery is activated.
4. It takes approximately 2 hours to fully charge the remote controller internal battery.
It is recommended to use the DJI BS30 Battery Station for charging. Otherwise, use a
certied USB-C charger with a maximum rated power of 65 W and maximum voltage of 20 V
such as the DJI 65W Portable Charger.
Fully discharge and charge the remote controller every three months. The battery depletes
when stored for an extended period.
If a WB37 battery is installed in the remote controller, the WB37 battery will be charged at the
same time. The WB37 battery can also be charged by inserting to the BS30 battery station.
The remote controller cannot be powered on before activating the internal battery.
Make sure to use the included USB-C to USB-C cable for optimal charging.
Charging Options
A. The internal battery of the remote controller can be charged with a charging device or the inserted
external WB37 battery. It takes approximately two hours to fully charge the internal battery with a
charging device. The internal battery can be charged up to 50% with the external battery. Charging
with the external battery is not possible after the remote controller is powered o.
