Available models
Model Nr.
Power ratings
AC TRACTION
PAC1255T4-**
96-120V 550Arms
PAC970T4-**
60-96V 700Arms
PAC960T4-**
60-96V 600Arms
PAC945T3-**
60-96V 450Arms
PAC927T2-**
60-96V 270Arms
PAC914T1-**
60-96V 140Arms
PAC480T4-**
24-48V 800Arms
PAC460T3-**
24-48V 600Arms
PAC445T2-**
24-48V 450Arms
PAC425T1-**
24-48V 250Arms
PMS TRACTION
PMS1255T4-**
96-120V 550Arms
PMS970T4-**
60-96V 700Arms
PMS960T4-**
60-96V 600Arms
PMS945T3-**
60-96V 450Arms
PMS927T2-**
60-96V 270Arms
PMS914T1-**
60-96V 140Arms
PMS480T4-**
24-48V 800Arms
PMS460T3-**
24-48V 600Arms
PMS445T2-**
24-48V 450Arms
PMS425T1-**
24-48V 250Arms
IPM TRACTION
IPM1255T4-**
96-120V 550Arms
IPM970T4-**
60-96V 700Arms
IPM960T4-**
60-96V 600Arms
IPM945T3-**
60-96V 450Arms
IPM927T2-**
60-96V 270Arms
IPM914T1-**
60-96V 140Arms
IPM480T4-**
24-48V 800Arms
IPM460T3-**
24-48V 600Arms
IPM445T2-**
24-48V 450Arms
IPM425T1-**
24-48V 250Arms
Resolver option
Devices with part number ending with “R” letter, have a special hardware and firmware able to work with a resolves as
motor sensor.
On those devices, standard firmware con not be loaded.
For resolver technical specification and connection, please refer to “APPENDIX D - Resolver”.
