DMC Sigma2N - Menu 5.8 Stall Protection

Simga2N Traction Advanced Manual– V1.3 Page 114 (166) ©2021 DMC GmbH Herten Germany
Menu 5.8 “Stall protection”
Cal.
Ref.
Parameter name “Calibrator text”
Range
Step
size
Default
Index
Sub-
index
1
Torque threshold for stall protection
“TrqTHLim”
1.0% - 100.0%
0.1%
100.0%
0x260A
0x1
2
Stall protection timer “StallTim”
0.0s – 120.0s
0.1s
60.0s
0x260A
0x2
M5.8-1 Torque threshold for stall protection “TrqTHLim”
M5.8-2 Stall protection timer “StallTim”
A motor stall protection is available to prevent to keep motor at full current and no speed for long time.
If the motor is stuck at zero speed with a toque greater than “M5.8-1 Torque threshold for stall protection
“TrqTHLim”” and for a time longer than “M5.8-2 Stall protection timer “StallTim”” the controller stops giving
power to the motor and a motor stall condition is detected.
Setting to 100% the “M5.8-1 Torque threshold for stall protection “TrqTHLim”” the function is disabled. As
default stall protection is disabled.
