Switching Frequency: Controller frequency is 8KHz (centre aligned PWM switching). Motor frequency 16KHz.
Electrical Isolation: Enclosure to any live part = 1KV. Controller internal insulation specified at >10MΩ @500V DC.
Reverse Battery Polarity: If line contactor installed according to the manual, yes.
I/O details: See light wiring diagram.
Power consumption: 40÷60W without driving digital outputs.
CAN chip current: 60mA in full CAN load condition.
Environmental
Impact Protection (IP): The enclosure is protected to IP65 (when AMP seal Connector fitted)
Vibration: 6G, 40-200Hz for 1 hour, in x, y and z planes.
Operating Temperature: -30
o
C to +40
o
C ambient around controller.
Storage Temperature: -40
o
C to +70
o
C.
Humidity: 95% maximum, non-condensing.
Humidity Resistance: Ingress protected, watertight AMP seal connector
Safety: Designed to the requirements of machine directive 2006/42/EC, safety of industrial trucks
EN1175-1:1998+A1:2010, EN13849-1, UL94.
The vehicle manufacturer is responsible for the compliance of the complete system with the
appropriate regulations.
EMC: EN 12895 (2015), (Immunity tested at 30V/M)
EN 61000-6-3 (2007) +A1 (2011) + AC (2005) (Residential Emissions, Class B)
EN 61000-6-2 (2005) + AC (2005) (Industrial Immunity)
The machine manufacturer is responsible for the compliance of the complete system with the
appropriate regulations.
