Simga2N Traction Advanced Manual– V1.3 Page 163 (166) ©2021 DMC GmbH Herten Germany
Mechanical
Details: See mechanical drawings.
Enclosure: Aluminium heat sink with ABS plastic cover.
Power connections: Vertical Copper studs.
Hexagonal: Fixing torque 9.5Nm (Slot screws are recommended!)
Slot screw: Recommended, fixing torque 9.5Nm (Brass)
Bolt length: Max 20mm incl. washer and spring washer
Weight: Size1: 3.25kg; Size2: 4.1kg; Size3: 4.9kg; Size4: 6.2kg;
Always use a torque wrench when fixing the power terminals.
Exceeding the maximum specified torque can cause serious damage to the controller and warranty
might be void.
Too long bolts damage the controller.
