Pin 25 CAN H2

CAN High communications can line to the Calibrator, Display or other Controller(s) CAN Devices.

• The can communication lines are referred to the battery 0V (ground).

Pin 26 CAN L2

CAN Low communications can line to the Calibrator, Display or other Controller(s)/CAN Devices.

• The can communication lines are referred to the battery 0V (ground).

Pin 27 Sensor supply +5V / +12V

Supply output for motor position/speed sensor (Ananlog Sine/Cosine or Hall Sensor). It delivers 5V or 12V

according to the parameter “M4-3 Sensor supply voltage “SenSuppV”” If it is set to 0 the supply is 5V, if set to 1

supply is 12V. The current capability is 70 mA.

Pin 28 Hall 1 i/p

This pin has to be connected to Hall sensor channel 1 if Hall sensor technology is selected by means of “M4-2

Sensor technology “SensType”” (set to 1).

Pin 29 Hall 2 i/p

This pin has to be connected to Hall sensor channel 2 if Hall sensor technology is selected by means of “M4-2

Sensor technology “SensType”” (set to 1).

Pin 30 Hall 3 i/p

This pin has to be connected to Hall sensor channel 3 if Hall sensor technology is selected by means of “M4-2

Sensor technology “SensType”” (set to 1).

Pin 31 Sensor supply 0V

This pin is the ground line for speed/position sensor.

Pin 32 Motor Sensor Sine

This pin has to be connected to Sine output of analog sine cosine sensor if SineCos sensor technology is selected

by means of “M4-2 Sensor technology “SensType”” (set to 0).

Pin 33 Motor Sensor CoSine

This pin has to be connected to Cosine output of analog sine cosine sensor if SineCos sensor technology is selected

by means of “M4-2 Sensor technology “SensType”” (set to 0).

Pin 34 Thermistor AD4 i/p

This pin has to be connected to the anode of KTY84-130 thermistor or to one side of and Pt 1000 ohm 0°C thermal

sensor. The motor thermal sensor type can be selected by parameter “M7-1 Motor Temp Sensor Type

“MtempTyp””

Pin 35 Thermistor 0V

This pin has to be connected to the cathode (black lined side) of KTY84-130 thermistor or Pt 1000 ohm 0°C thermal

sensor. The motor thermal sensor type can be selected by parameter “M7-1 Motor Temp Sensor Type

“MtempTyp””
