4 Menu 2 “Status”
The status menu shows various parameters from the controller which can be useful to help tune and optimize vehicle’s
performance. By pressing the decrement ( ) or the increment ( ) button on the calibrator extra information about the
selected status variable are displayed.
Cal.
Ref.
Item
Calibrator text
Step size
Service log info & Notes
1
Drive hours counter
Drive
0.1 Hrs
shows key hours
2
Current Fault code
CurFault
Fxx
Show fault time
Sub code
3
Battery Discharge
Indicator
BDI
1 %
Raw BDI value incl.
state (WO & CO)
BDI states
(see “M2-3 BDI
States table”)
4
Controller Temperature
CtrlTmp
0.1 C
Min. temperature
Max. temperature
5
Motor Temperature
MotTemp
0.1 C
Shows N/A when disabled.
Min. temperature
Max. temperature
6
Drive State
DriveSta
--
See “M2-6 Drive and brake status table”
7
Speed Limit
SpeedLim
--
See “M2-7 Speed limits table”
8
Torque Limit
TrqLimit
--
See “M2-8 Torque limits table”
9
Motor Limit
MotorLim
--
See “M2-9 Motor limits table”
10
Battery Voltage
BatVolts
0.1 V
Max. Voltage
11
Capacitor Voltage
CapVolts
0.1 V
Max. Voltage
12
Battery current
I_batter
0.1 A
13
Motor current
I_Motor
0.1 Arms
Id Current
Iq Current
14
Motor voltage
V_Motor
0.1 Vrms
Reactive Power
Motor Power
Reached maximum
output voltage (VL)
15
Stator speed
StatorSpd
0.1 Hz
16
Rotor speed
RotorSpd
0.1 Hz
RPM speed
17
Accelerator demand
Accel
0.1 %
Steer pot demand
Foot brake demand
18
Target demand
DemTrgt
0.1 %
+
CW
−
CCW
19
Ramped demand
DemRampd
0.1 %
+
CW
−
CCW
20
Speed limit %
21
Drive torque limit
DrvTrqL
0.1 %
Torque limit CW
22
Brake torque limit
BrkTrqL
0.1 %
Torque limit CCW
23
Actual torque
TrqAct
0.1 %
Actual torque in
Nm
Maximum torque in
Nm
+
CW
−
CCW
24
Actual speed
SpeedAct
0.1 %
+
CW
−
CCW
25
Actual Flux
FluxDem
0.1 %
Actual Flux
26
Filtered capacitor
voltage
27
Vehicle Speed
Vehicle
1 Kph
To reset the max and min temperatures logged data, press the + and – button at the same time when
the controller is in neutral.
