M3-19P Driver output 3 configuration “Drv3Cfg”
This sets the configuration for Driver Output 3.
• If set to 0, no function is assigned to digital output driver 3 (pin 16 in 35 way connector)
• If set to 1, digital output 3 is activated if motor temperature is higher than threshold “M3-21T Motor
Temperature threshold (for output driver) “MotTmpTh”” and deactivated when motor temperature gets lower
than threshold “M3-21T Motor Temperature threshold (for output driver) “MotTmpTh””- 8 °C of hysteresis.
• If set to 2, digital output 3 is activated if controller temperature is higher than threshold “M3-22T Controller
Temperature threshold (for output driver) “CtrTmpTh””, and deactivated when controller temperature gets
lower than threshold “M3-22T Controller Temperature threshold (for output driver) “CtrTmpTh””- 8 °C of
hysteresis .
• If set to 3, digital output 3 is activated if motor temperature is higher than threshold “M3-21T Motor
Temperature threshold (for output driver) “MotTmpTh”” OR if controller temperature is higher than threshold
“M3-22T Controller Temperature threshold (for output driver) “CtrTmpTh””, while it is deactivated when motor
temperature gets lower than threshold “M3-21T Motor Temperature threshold (for output driver)
“MotTmpTh””- 8 °C of hysteresis AND controller temperature gets lower than threshold “M3-22T Controller
Temperature threshold (for output driver) “CtrTmpTh””- 8 °C of hysteresis.
M3-20P Motor Temperature threshold (for output driver) “MotTmpTh”
M3-21P Controller Temperature threshold (for output driver) “CtrTmpTh”
These two settings represent the temperature thresholds to drive output 2 and/or 3 according to setting “M3-19T
Driver output 2 configuration “Drv2Cfg”” and “M3-20T Driver output 3 configuration “Drv3Cfg””.
M3-22P n/a
This setting is not active in PMS software
M3-23P Calibration Data option “CalValue”
Not used yet. For future development
M3-24P Load Defaults “LoadDefs”
If this parameter is set to 1 (load defaults) all the setting in all menus will be restored to the default factory values.
This parameter requires a key cycle off-on to be effective.
