DMC SuperSigma2 User Manual

SuperSigma2 AM PMS – V1.5.6 17-1-2020 Page 73 (97) ©2019 DMC GmbH Herten Germany
8 Menu 6 “PMS Motor Advanced”
These parameters are reported for indication only and it is not possible to modify them without the assistance of DMC
engineers.
Cal.
Ref.
Parameter
Calibrator
text
Min.
Max.
Step
size
Default
1
Decouple Iq and Id controllers
Decouple
0
1
1
0
2
Enable software PWM algorithm delay compensation
PWMDelay
0
1
1
1
3
Limit torque controller during Voltage limiting
VoltSat
0
1
1
0
4
Speed Control Filter
SCFilter
0
1
1
1
5
Enable Voltage Limiter
VoltCtrl
0
1
1
0
6
Speed filter cut-off frequency
Fspdfilt
4 Hz
400 Hz
1 Hz
80 Hz
7
Percentage of correction for inductance value
DecoLeak
0 %
180 %
1 %
100 %
8
Back EMF correction factor
BEMFCorr
0 %
180 %
1 %
100 %
9
Speed estimator rate
Obs. Rate
2%
65%
1%
30%
10
Resistance compensation gain
R. Gain
70%
100%
1%
70%
11
Current compensation gain
Curr. Gain
0%
60%
1%
28%
12
Start Torque
StartTrq
0%
100%
1%
40%
13
Start Current
StartCur
0%
50%
1%
30%
14
Maximum radius voltage
Vmodmax
90%
102%
1%
102%
M6-1 Decouple Iq and Id controllers “Decouple”
M6-2 Enable software PWM algorithm delay compensation “PWMDelay”
M6-3 Limit torque controller during Voltage limiting “VoltSat”
M6-4 Speed Control Filter “SCFilter”
M6-5 Enable Voltage Limiter “VoltCtrl”
M6-6 Speed filter cut-off frequency “Fspdfilt”
M6-7 Percentage of correction for inductance value “DecoLeak”
M6-8 Back EMF correction factor “BEMFCorr”
These parameters are only for advanced DMC servicing.
M6-9 Speed estimator rate “Obs.Rate”
M6-10 Resistance compensation gain “R gain”
M6-11 Current compensation gain “CurrGain”
M6-12 Start Torque “StartTrq”
M6-13 Start Current “StartCur”
These parameters are used in Sensorless applications [4]. Refer to DMC for details.
M6-14 Maximum radius voltage “Vmodmax”
From SW release V02.08.05 it is possible to deliver full PWM voltage output to motor for achieving maximum possible
voltage from the battery. This is possible by increasing the value of this setting. If set to 102% full PWM wave will be
provided at high speed.
To take advantage of this there are two chances:
1) Set “Vmodmax” to 102% before doing autotuning.
2) Set “Vmodmax” to 102% and do recalculation.
Suggested option is number 1)
If after increasing the “Vmodmax” the motor behavior becomes unstable at high speed bring back “Vmodmax” to 95%
and perform recalculation.
