DMC SuperSigma2 - 13 Use of Calibrator and PC interface

To Next Page

To Previous Page

13 Use of Calibrator and PC interface

Starting from V02.07.01 the V01.02.08 DMC PC interface or later for SuperSigma2 has to be used.

V01.02.08 DMC PC interface can open setting list generated with previous releases.

V01.02.08 DMC PC interface is dedicated to SuperSigma2 generation but it is still compatible with

Sigma Drive controllers.
