DMC SuperSigma2 User Manual

SuperSigma2 AM PMS – V1.5.6 17-1-2020 Page 55 (97) ©2019 DMC GmbH Herten Germany
M3-17T Accelerator supply wire off detection ”SplyWrOf”
This sets how the wire off detection for accelerator is detected.
• If set to 0, no wire off detection on accelerator potentiometer supply lines is active.
• If set to 1, 0V wire off detection is enabled (“Pin 10 Analogue supply 0V” of 35-Way connector).
• If set to 2, 5V wire off detection is enabled ( “Pin 8 Analogue supply 5V” of 35-Way connector).
• If set to 3, both 0V and 5V wire off detection are enabled.
This parameter requires a key cycle off-on to be effective.
M3-18T Standby timer ”StdByDly”
This sets a period of time after which the Line Contactor will be de-energized if there is no drive activity and the seat or
tiller switch is open.
When the seat or tiller switch is closed, the controller powers up, performs all necessary hardware and software checks
and closes the line contactor.
• If set to 0, then the feature is deactivated and no timer is used.
• If set from 0.5 to 10 [minutes] the stand-by timer is considered and active.
M3-19T Driver output 2 configuration “Drv2Cfg”
This sets the configuration for Driver Output 2.
• If set to 0, standard electro-magnetic brake function is assigned to digital output driver 2 (“Pin 16 Contactor 2
o/p (Magnet Brake - Fan control)”) in 35 way connector)
• If set to 1, digital output 2 is activated if motor temperature is higher than threshold “M3-21T Motor
Temperature threshold (for output driver) “MotTmpTh”” and deactivated when motor temperature gets lower
than threshold “M3-21T Motor Temperature threshold (for output driver) “MotTmpTh””- 8 °C of hysteresis.
• If set to 2, digital output 2 is activated if controller temperature is higher than threshold “M3-22T Controller
Temperature threshold (for output driver) “CtrTmpTh””, and deactivated when controller temperature gets
lower than threshold “M3-22T Controller Temperature threshold (for output driver) “CtrTmpTh””- 8 °C of
hysteresis .
• If set to 3, digital output 2 is activated if motor temperature is higher than threshold “M3-21T Motor
Temperature threshold (for output driver) “MotTmpTh”” OR if controller temperature is higher than threshold
“M3-22T Controller Temperature threshold (for output driver) “CtrTmpTh””, while it is deactivated when motor
temperature gets lower than threshold “M3-21T Motor Temperature threshold (for output driver)
“MotTmpTh””- 8 °C of hysteresis AND controller temperature gets lower than threshold “M3-22T Controller
Temperature threshold (for output driver) “CtrTmpTh””- 8 °C of hysteresis.
M3-20T Driver output 3 configuration “Drv3Cfg”
This sets the configuration for Driver Output 3.
• If set to 0, standard Power Steer function is assigned to digital output driver 3 (“Pin 17Contactor 3 o/p
(Powersteer - Fan control) in 35 way connector)
• If set to 1, digital output 3 is activated if motor temperature is higher than threshold “M3-21T Motor
Temperature threshold (for output driver) “MotTmpTh”” and deactivated when motor temperature gets lower
than threshold “M3-21T Motor Temperature threshold (for output driver) “MotTmpTh””- 8 °C of hysteresis.
• If set to 2, digital output 3 is activated if controller temperature is higher than threshold “M3-22T Controller
Temperature threshold (for output driver) “CtrTmpTh””, and deactivated when controller temperature gets
lower than threshold “M3-22T Controller Temperature threshold (for output driver) “CtrTmpTh””- 8 °C of
hysteresis .
• If set to 3, digital output 3 is activated if motor temperature is higher than threshold “M3-21T Motor
Temperature threshold (for output driver) “MotTmpTh”” OR if controller temperature is higher than threshold
“M3-22T Controller Temperature threshold (for output driver) “CtrTmpTh””, while it is deactivated when motor
temperature gets lower than threshold “M3-21T Motor Temperature threshold (for output driver)
“MotTmpTh””- 8 °C of hysteresis AND controller temperature gets lower than threshold “M3-22T Controller
Temperature threshold (for output driver) “CtrTmpTh””- 8 °C of hysteresis.
M3-21T Motor Temperature threshold (for output driver) “MotTmpTh”
M3-22T Controller Temperature threshold (for output driver) “CtrTmpTh”
These two settings represent the temperature thresholds to drive output 2 and/or 3 according to setting “M3-19T Driver
output 2 configuration “Drv2Cfg”” and “M3-20T Driver output 3 configuration “Drv3Cfg””.
