DMC SuperSigma2 User Manual

SuperSigma2 AM PMS – V1.5.6 17-1-2020 Page 23 (97) ©2019 DMC GmbH Herten Germany
3 Menu 1 “Adjustment”
This menu includes all the adjustment for a more comfortable driving experience.
Please notice that the adjustment menu’s parameters are visible and adjustable on the calibrator according to the settings
in “Menu 3 “Controller Setup””.
For example the dual motor parameters (from “M1-61T Dual motor cut out ”DMcut”” to “M1-67T Dual motor speed 3
”DMspd3””) will be visible only if dual motor control is enabled (“M3-14T Single or Dual Motor ”Si/DL/DR””).
It is therefore important to properly set up and configure Controller’s settings in “Menu 3 “Controller Setup””, recycle the
key and then move to Adjustment menu, where only active parameters will be visible.
DMC PC programmer interface is displaying always all parameters.
3.1 Menu 1 “Traction Adjustments”
Cal.
Ref.
Parameter
Calibrator
text
Min.
adjust
Max.
adjust
Step
size
Default
1
Acceleration delay
Accel
0.1 s
20.0 s
0.1 s
2.0 s
2
Deceleration delay
Decel
0.1 s
20.0 s
0.1 s
2.0 s
3
Creep speed
Creep
0.0 %
20.0 %
0.1 %
0.0 %
4
Creep speed ramp time
CreepRmp
0.1 s
20.0 s
0.1 s
2.5 s
5
Maximum speed forward
SpdMaxF
0.0 Hz
600.0 Hz
0.1 Hz
100.0 Hz
6
Maximum speed reverse
SpdMaxR
0.0 Hz
600.0 Hz
0.1 Hz
100.0 Hz
7
Neutral brake torque (torque mode only)
NBrake
0 %
100 %
1 %
10 %
8
Neutral brake ramp time
NBrkRamp
0.1 s
20.0 s
0.1 s
8.0 s
9
Neutral brake end delay
NBrkEnd
0.0 s
10.0 s
0.1 s
0.0 s
10
Direction brake torque (torque mode only)
DBrake
1 %
100 %
1 %
100 %
11
Direction brake ramp time
DBrkRamp
0.1 s
20.0 s
0.1 s
1.0 s
12
Max. direction change speed
MxDbrkSp
1 %
100 %
1 %
100 %
13
Foot brake torque (torque mode only)
FBrake
0 %
100 %
1 %
50 %
14
Foot brake ramp time
FbrkRamp
0.1 s
20.0 s
0.1 s
1.0 s
15
Speed threshold to enter end of braking
mode
SpdThEbM
0.1 %
50.0 %
0.1 %
15 %
16
Ramp time from the speed threshold to
zero
SpdRmpTm
0.1 s
20.0 s
0.1 s
3.0 s
17
Ramp time from the speed threshold to
zero low TH
SpdRTmFB
0.1 s
20.0 s
0.1 s
0.4 s
18
Zero Speed threshold to enter hill hold or
neutral brake end
ZSpdTh
0.1 %
10.0 %
0.1 %
0.2 %
19
Hill hold time
HHTime
0 s
60 s
1 s
5 s
20
Restraint hill hold speed
HHspeed
0.0 Hz
5.0 Hz
0.1 Hz
3.0 Hz
21
Restraint hill hold torque threshold
HHTrqTH
0.1 %
35.0 %
0.1 %
1.5 %
22
Cutback speed 1 (I/O 5-6 set to Speed)
Speed1
0.0 Hz
600.0 Hz
0.1 Hz
100.0 Hz
23
Inching speed (I/O 5-6 set to Inching)
InchSpd
0.0 Hz
25.0 Hz
0.1 Hz
10.0 Hz
24
Acceleration delay 1
Accel1
0.1 s
20.0 s
0.1 s
3.0 s
25
Deceleration delay 1
Decel1
0.1 s
20.0 s
0.1 s
3.0 s
26
Maximum Drive Torque 1 (Torque Mode
Only)
MxDrTrq1
0 %
100 %
1 %
100 %
27
Neutral Brake Torque 1 (Torque Mode
Only)
NBrkTrq1
0 %
100 %
1 %
10 %
28
Neutral brake ramp time 1
NBrkRmp1
0.1 s
20.0 s
0.1 s
3.0 s
29
Direction Brake torque 1 (Torque Mode
Only)
DBrkTrq1
0 %
100 %
1 %
100 %
30
Direction brake ramp time 1
DBrkRmp1
0.1 s
20.0 s
0.1 s
3.0 s
31
Foot Brake Torque 1 (Torque Mode Only)
FBrkTrq1
0 %
100 %
1 %
50 %
32
Foot brake ramp time 1
FBrkRmp1
0.1 s
20.0 s
0.1 s
3.0 s
33
Cutback speed 2 (I/O 5-6 set to Speed)
Speed2
0.0 Hz
600.0 Hz
0.1 Hz
100.0 Hz
34
Inching time (I/O 5-6 set to Inching)
InchTime
0.1 s
10.0 s
0.1 s
2.5 s
35
Acceleration delay 2
Accel2
0.1 s
20.0 s
0.1 s
4.0 s
36
Deceleration delay 2
Decel2
0.1 s
20.0 s
0.1 s
4.0 s
37
Maximum Drive Torque 2 (Torque Mode
Only)
MxDrTrq2
0 %
100 %
1 %
100 %
38
Neutral Brake Torque 2 (Torque Mode
Only)
NBrkTrq2
0 %
100 %
1 %
10 %
