DMC SuperSigma2 User Manual

SuperSigma2 AM PMS – V1.5.6 17-1-2020 Page 2 (97) ©2019 DMC GmbH Herten Germany
Modification History:
Revision
Issue Date
Author
Changes
1.0
04-01-2017
FM
Concept matching firmware V02.07.01
1.1
01-04- 2017
FM
Match firmware V02.07.03
1.2
01-11-2017
YS
Match firmware V02.08.00
1.2.1
19-02-2018
RP
Corrected mechanical drawing Size 1
1.3
13-03-2018
FM
V02.08.01 Improved the inching in traction, added Shared Line contactor
compatible with Control Via CAN HMI, enable the creep ramp time for traction and
pump, add serial numbers visible in About menu of calibrator.
1.3.1
22-05-2018
RP
Update Layout
1.4
04-06-2018
FM
V02.08.02 Improved F30 (overspeed) management (pump-traction). Increased
available output voltage for AC motor(pump.traction). For traction: improved
inching, footbrake operation, scale of accel pot in traction speed mode. Added adj
17 in traction for torque mode 3 for better end of braking in footbrake operation.
Changed some default values. Included Park Icon for display.. Improved F12 and
F13 management. Improved PC interface settings download. Improved the
function inhibit of change of direction.
1.4.1
24-08-2018
FM
Update Layout and Cross-references. Minor textual errors corrected
1.4.2
15-01-2019
FM
Update Nominal RMS motor current for tuning
1.5.0
04-09-2019
SM
Match firmware V02.09.00, textual error corrected, updated layout
1.5.1
04-10-2019
FM
Review and fixed typos
1.5.2
14-10-2019
SM
Added F7 sub codes, minor graphical fixes in controller setup table
1.5.3
03-11-2019
AvB
Update Layout
1.5.4
09-01-2020
SM
Fixed M3-17T parameter description, fixed menus defaults and ranges
1.5.5
15-01-2020
SM
Updated reference to QRM manual, updated max speed limits defaults in
Adjustment, AT and Limits menus.
1.5.6
17-01-2020
SM
Updated reference to QRM manual, added walkie-related parameters, added
warnings for FW and RV inputs both active, modified F10 description

DMC SuperSigma2 Specifications

General

Brand	DMC
Model	SuperSigma2
Category	Engine
Language	English
