SuperSigma2 AM PMS – V1.5.6 17-1-2020 Page 48 (97) ©2019 DMC GmbH Herten Germany
Options (defaults are in bold)
Accelerator supply wire
off detection
0 = No supply wire off detection
1 = 0V wire off detection enabled
2 = 5V wire off detection enabled
3 = Both 0V and 5V wire off detection
Adjustable from 0 to 10 Minutes.
Default is 0 (0=Off)
Drive output 2
Configuration
0 = EM brake function
1 = motor temperature cooling enabled
2 = controller temperature cooling enabled
3 = both motor and controller temperature cooling
enabled
Drive output 3
Configuration
0 = Power Steer function
1 = motor temperature cooling enabled
2 = controller temperature cooling enabled
3 = both motor and controller temperature cooling
enabled
Drive Output Motor Temp
TH
Adjustable from 10 to 127 °C. Default is 70 °C
Drive Output Controller
Temp TH
Adjustable from 10 to 100 °C. Default is 45 °C
Line Contactor pull-in
level
Adjustable from 50% to 100% Ubatt.to limit inrush
current. Default is 90%
Line Contactor pull-in
time out
Line Contactor pull in time out. Default is 10sec.
Drive torque during
braking
0 = no drive torque allowed during brake
1 = drive torque is allowed during brake
Line Contactor Coil pull-in
Voltage
Adjustable from7% to 100% Ubatt Default is 100%
Line Contactor Coil
Holding voltage
Adjustable from 7% to 100% Ubatt Default is 100%
Digital output 2 pull-in
voltage
Adjustable from 7% to 100% Ubatt Default is 100%
Digital output 2 hold
voltage
Adjustable from 7% to 100% Ubatt Default is 100%
Digital output 3 pull-in
voltage
Adjustable from 7% to 100% Ubatt Default is 100%
Digital output 3 hold
voltage
Adjustable from 7% to 100% Ubatt Default is 100%
0 = Don't load defaults
1 = Load defaults
(*) Recycle the key switch to make changes active. (Also indicated on calibrator ‘key’)
