Installation
21
XR2400F Installation Guide
2500 N. Partnership Boulevard Springfield, MO 65803 www.dmpnet.com Digital Monitoring Products
Cannot exceed 7.7 Ah with one 367 Battery
Cannot exceed 15.4 Ah with two 367 Batteries
Cannot exceed 23.1 Ah with three 367 Batteries
Cannot exceed 30.8 Ah with four 367 Batteries
STANDBY BATTERY POWER CALCULATIONS Standby Current Alarm Current
XR2400F Control Panel 80mA ______ mA 80mA ______ mA
Relay Outputs 1-2 (ON) Qty _____ x 30mA ______ Qty _____ x 30mA ______
Voltage Outputs 3-10 (ON) Qty _____ x 5mA ______ Qty _____ x 5mA ______
Active Zones 1-8 Qty _____ x 1.6mA ______ Qty _____ x *2mA ______
Active Zones 9-10 Qty _____ x 4mA ______ Qty _____ x 30mA ______
2-Wire Smokes Qty _____ x .1mA ______ Qty _____ x .1mA ______
Panel Bell Output 500mA ______
893/893A Dual Phone Line Module 12mA ______ 50mA ______
460 Interface Adaptor Card 7mA ______ 7mA ______
462N Network Interface Card Qty _____ x 50mA ______ Qty _____ x 50mA ______
462P Printer Interface Card Qty _____ x 50mA ______ Qty _____ x 50mA ______
472 H
ARD-WIRE-LESS Interface Card Qty _____ x 85mA ______ Qty _____ x 85mA ______
481 Expansion Interface Card Qty _____ x 15mA ______ Qty _____ x 15mA ______
485 Access Control Interface 45mA ______ 45mA ______
865 Style Y or Z Notification Module Qty _____ x 26mA ______ Qty _____ x 85mA ______
866 Style W Notification Module Qty _____ x 45mA ______ Qty _____ x 75mA ______
867 LX-Bus Style W Notification Module Qty _____ x 30mA ______ Qty _____ x 85mA ______
630F, 690, 790, 791, 793 Qty _____ x 100mA ______ Qty _____ x 100mA ______
Active Zones (EOL installed) Qty _____ x 1.6mA ______ Qty _____ x *2mA ______
670, 770, 771 Keypads Qty _____ x 100mA ______ Qty _____ x 100mA ______
Annunciator (ON) Qty _____ x 20mA ______
Active Zones (EOL installed) Qty _____ x 1.6mA ______ Qty _____ x *2mA ______
733 Wiegand Interface Qty _____ x 30mA ______ Qty _____ x 30mA ______
Annunciator (ON) Qty _____ x 20mA ______
Active Zones (EOL installed) Qty _____ x 1.6mA ______ Qty _____ x *2mA ______
736P Radionics Popit Interface Qty _____ x 25mA ______ Qty _____ x 25mA ______
Radionics Popex, Octopopit, Popits Qty _____ x __mA ______ Qty _____ x __mA ______
738A Ademco Wireless Interface Qty _____ x 75mA ______ Qty _____ x 75mA ______
w/Receiver
740/741/743 SC Keypads Qty _____ x 50mA ______ Qty _____ x 100mA ______
Active Zones (EOL installed) Qty _____ x 1.6mA ______ Qty _____ x *2mA ______
Annunciator (ON) Qty _____ x 20mA ______
710 Bus Splitter/Repeater Qty _____ x 30mA ______ Qty _____ x 30mA ______
711, 711E, or 714 Zone Expander Qty _____ x 7mA ______ Qty _____ x 7mA ______
Active Zones (EOL installed) Qty _____ x 1.6mA ______ Qty _____ x *2mA ______
714-8 or 714-16 Zone Expander Qty _____ x 20mA ______ Qty _____ x 20mA ______
Active Zones (EOL installed) Qty _____ x 1.6mA ______ Qty _____ x *2mA ______
715 Zone Expander Qty _____ x 7mA ______ Qty _____ x 7mA ______
Active Zones (EOL installed) Qty _____ x 4mA ______ Qty _____ x *30mA ______
2-Wire Smokes Qty _____ x .1mA ______ Qty _____ x .1mA ______
715-8 or 715-16 Zone Expander Qty _____ x 20mA ______ Qty _____ x 20mA ______
Active Zones (EOL installed) Qty _____ x 4mA ______ Qty _____ x *30mA ______
2-Wire Smokes Qty _____ x .1mA ______ Qty _____ x .1mA ______
716 Output Expander Qty _____ x 7mA ______ Qty _____ x 7mA ______
Active Form C Relays Qty _____ x 28mA ______
717 Graphic Annunciator Qty _____ x 10mA ______ Qty _____ x 10mA ______
Annunciator Outputs Qty _____ x 1mA ______
521LX and LXT Smoke Detectors Qty _____ x 8.8mA ______ Qty _____ x 28mA ______
Aux. Powered Devices on Terminals 7 and 11 ______ mA ______ mA
(Other than keypads and LX-Bus modules)
Total Standby ________ mA Total Alarm ________ mA
Total Standby _________ mA x Number of standby hours needed ______ = _________ mA/hours
Total Alarm + _________ mA/hours
Total _________ mA/hours
x
.001_____
= _________ Amp/hrs Required
* Based on 10% of active zones in alarm condition
