System Wiring Diagrams
36
XR2400F Installation Guide
Digital Monitoring Products www.dmpnet.com 2500 N. Partnership Boulevard Springfield, MO 65803
EARTH GROUND
+ Signal Voltage In
Alternate Alarm
Combo Alarm
GROUND
GROUND
- Signal Voltage In
- To Remote Receiver
+ To Remote Receiver
Auxiliary Power Input
EARTH GROUND
+ Signal Voltage In
Alternate Alarm
Combo Alarm
GROUND
GROUND
- Signal Voltage In
- To Remote Receiver
+ To Remote Receiver
Auxiliary Power Input
To Telephone Line
To Telephone Line
Reversing Relay Module
Radionics Model D127
12 VDC Supply
5mA Standby
55mA Alarm
Reversing Relay Module
Radionics Model D127
12 VDC Supply
5mA Standby
55mA Alarm
}
}
Up to 60 hours of battery standby time
can be supplied using three or four
7.0Ah sealed lead acid batteries.
Four 7.0Ah batteries may be required
based on total current draw of all devices
connected to the panel. See section 6.6.
To connect four batteries to the XR200
Command Processor panel, use three
Model 318 Battery Harnesses.
Outputs 3 to 6
supply up to
50mA at 12 VDC.
Note: Output 3 must be
programmed as a Fire
Alarm Output and Output
4 must be programmed
as a Fire Trouble Output.
See Sections 8.5D and
8.5E of the XR200
Programming Manual
(LT-0196).
Fire Trouble Output 4 - White/Yellow
Model 430
Output Harness
Intended for connection to a polarity reversal
circuit of a Remote Station receiving unit
having compatible ratings.
All modules must be installed in
a listed enclosure connected by
no more than 20 feet of conduit.
J4
J16
Command Processor Reset
K4
J11J12
DD, MPX
Selection
Tamper Header
AC
1
234
56
78
10 11 12
13
14
15
16
17
18
19
AC +B -B
BELL
GND
SMK
GND
9
RED
YEL GRN BLK
20
21
22 23 24 25
26
27 28
Z1 Z2
GND
GND
GND
GND
Z3
Z4 Z5 Z6 Z7 Z8 Z9- Z9+ Z10- Z10+
Answering Machine
Bypass Relay
Use Model 305
K2
Phone Jack Connector
J3
Lithium Battery
K7
K6
Relay Output 1
Use Model 305
Relay Output 2
Use Model 305
J6
J2
Fire Alarm Output 3 - White/Orange
= Supervised Circuit
S
S S S S
Output Header J2
All outputs must be connected
to devices located within the
same room as the control panel.
34.4 Remote Station reversing relay connection
