System Wiring Diagrams
XR2400F Installation Guide
2500 N. Partnership Boulevard Springfield, MO 65803 www.dmpnet.com Digital Monitoring Products
39
34.7 LX-Bus™ Module Connection
Each LX-Bus module must
be selected with its own
independent address from
00 to 99. A Supervisory
zone must be programmed
into the XR2400F to prop-
erly supervise
each module.
= Supervised Circuit
Normally Closed
Common
Normally Open
Form C Contacts
Typical
Relay 1
Relay 2
Relay 3
Relay 4
Open Collector
Annunciator Outputs
Optional LED wiring
50mA at 50 VDC resistive
Graphic Annunciator Module
DMP Model 717
10mA at 12 VDC
Output Expander Module
DMP Model 716
7mA at 12 VDC
LX-Bus Expansion Card
DMP Models 462N, 462P, 472, or 481.
Notification Circuit Module
DMP Model 867
S
S
S
S
S
S
S
S
S
Optional LED wiring
50mA at 50 VDC resistive
S
S
S
S
Black
Green
Yellow
Red
Data LED
Power Supply
Monitor LED
LX-Bus
wiring
BELL RELAY
ADDRESS
SUPERVISORY
ADDRESS
To additional LX-Bus modules
Bell Ring Style
Normal/Silence Switch
Bell Trouble LED
+
-
10K EOL Resistor
DMP Model # 308
12 or 24 VDC
12 or 24 VDC
UL Listed,
Polarized
Notification
Devices
Ground Fault LED
BELL
POWER
SUPPLY
TENS
ONES
TENS
ONES
1 Bell In +
2 Bell In -
3 Bell Out +
4 Bell Out -
5 Bell Trouble
6 Bell Trouble
7 PWR Mon.
8 Mon. RTN
Connect to panel
Supervisory zone
To Next Page
