OPERATING INSTRUCTIONS
XR2400F Addressable Fire Alarm Control Panel
NORMAL STANDBY CONDITION
When the system is in the normal standby condition, the display shows either the
time of day or a blank display.
ALARM CONDITION
When the system is in an alarm condition, the display shows the alarmed zone
name(s) followed by an alarm display.
KEYSWITCH OPERATION
In order to use the four function keys, the keyswitch must be turned to the enable
position.
ALARM SILENCE
To silence the alarm while the bell or siren is sounding, press the key labeled
"Silence" or enter your code number and press the COMMAND key. This silences
the alarm but does
not
cancel any alarm reports to the central station.
RESETTING DETECTORS
To reset a smoke or other detector, press the key labeled "Reset" or enter the User
Menu by pressing the COMMAND key until MENU? NO YES appears in the
display. Press the top row key under YES. The display shows ENTER CODE: - .
Enter your code number and press COMMAND. The display now shows ALARM
SILENCE?. Press the COMMAND key until SENSOR RESET? appears in the
display. Press any top row key.
TROUBLE CONDITION
When a device is in a trouble condition, the keyboard tones and displays the zone or
device name followed by TRBL. Press any top row key to silence.
SYSTEM TESTING
You should test the security system periodically to ensure proper operation. You can
do this by pressing the key labeled "Test" or through a function in the User Menu.
After entering the User Menu, press the COMMAND key until SYSTEM TEST?
displays. Press any top row key. The system bell, battery, and communication to the
central station system is then tested.
ALARM SERVICE
If service is required for this system, please contact:
Company
Address
Telephone
The operating instructions above should be attached to the front, or framed and located adjacent to, the Fire
Alarm Control Panel or a Remote Fire Command Center.
