10BaseT/10Base2 HUB
CPU2 F6150
or 10/100 Switch
(
401-0244
)
CAT5 or better Ethernet Cable (
401-0243)
to/from
the Ethernet Port on the PC and the HUB and the
HUB to the CPU2 F6150.
F6300 Power System Simulator User Guide
72A-2337-01 Rev. B 11/05 2-7
Figure 2.5 Computer to CPU2 F6150 with Switch/Hub
CPU2 F6150
CAT5 or better Ethernet cable (
401-0243
) to/from
the Ethernet port on the PC to the Crossover
10Base T Modular Adapter (
401-0242
) on the
CPU2 F6150 NETWORK connector.
Figure 2.6 Computer to CPU2 F6150 with a CAT5 Crossover Cable
