INSTALLATION
NOTE: When installing accessory drive belt onto
pulleys, make sure that belt is properly routed and
all V-grooves make proper contact with pulleys.
(1) If belt tensioner was removed, install tensioner
and mounting nut (Fig. 2). Torque mounting nut to
41 N·m (30 ft. lbs.).
(2) Position the drive belt over all pulleys except
for the water pump pulley (Fig. 1).
(3) Rotate tensioner counterclockwise and slip
the belt over the water pump pulley.
(4) Gently release tensioner.
(5) Install the air cleaner housing (Refer to 9 -
ENGINE/AIR INTAKE SYSTEM/AIR CLEANER
HOUSING - INSTALLATION).
