(5) Check stop lamps to verify they are operating
properly and not staying on when brake pedal is in
released position.
(6) Road test vehicle to ensure proper operation of
brakes (including ABS) and lamps.
CENTER HIGH MOUNTED
STOP LAMP UNIT
REMOVAL
(1) Open deck lid.
(2) Remove four bolts to battery compartment
cover and remove cover.
(3) Disconnect and isolate the battery negative
cable.
(4) Disconnect the one electrical connector inside
of deck lid.
(5) Remove, four nuts retaining the Center High
Mounted Stop Lamp (CHMSL) to the deck lid.
(6) Push CHMSL into trunk area and remove from
vehicle.
INSTALLATION
(1) Push CHMSL into deck lid.
(2) Install four nuts retaining the Center High
Mounted Stop Lamp (CHMSL) to the deck lid. Torque
nuts to 4 N·m (35 in lbs.).
NOTE: Make sure lamp is centered in deck lid open-
ing.
(3) Connect the one electrical connector inside of
deck lid.
(4) Connect the battery negative cable.
(5) Place battery access cover into place and install
four bolts.
(6) Close deck lid.
(7) Verify vehicle and system operation.
FOG LAMP - FRONT
REMOVAL
(1) Open deck lid.
(2) Remove four bolts to battery compartment
cover and remove cover.
(3) Disconnect and isolate the battery negative
cable.
(4) Remove access panel within wheel well (Fig. 5).
(5) Remove the fog lamp by turning 1/4 turn coun-
terclockwise and pulling straight out.
(6) Disconnect the electrical connector from the fog
lamp and remove from vehicle.
INSTALLATION
CAUTION: Do not touch the glass of halogen lamps
with fingers or other possibly oily surface. Reduced
lamp life will result.
(1) Connect the electrical connector to the fog
lamp.
(2) Install the fog lamp by turning 1/4 turn clock-
wise.
(3) Install the access panel within wheel well (Fig.
5).
(4) Connect the battery negative cable.
(5) Place battery access cover into place and install
four bolts.
(6) Close deck lid.
(7) Verify vehicle and system operation.
(8) Verify fog lamp aim. If adjustment is necessary,
(Refer to 8 - ELECTRICAL/LAMPS/LIGHTING -
EXTERIOR/HEADLAMP UNIT - STANDARD PRO-
CEDURE). At 25 feet on level surface, the fog lamp
beam should be 11 inches off floor on alignment
screen.
FOG LAMP UNIT - FRONT
REMOVAL
(1) Open deck lid.
(2) Remove four bolts to battery compartment
cover and remove cover.
(3) Disconnect and isolate the battery negative
cable.
(4) Remove fog lamp access cover (Fig. 5).
(5) Disengage fog lamp connector.
(6) Remove three screws attaching fog lamp to
front bumper fascia.
(7) Remove fog lamp from fascia.
INSTALLATION
(1) Install fog lamp unit to fascia.
Fig. 5 FOG LAMP ACCESS PANEL
8L - 6 LAMPS ZB
BRAKE LAMP SWITCH (Continued)
