MULTI-FUNCTION SWITCH CONTINUITY TEST
SWITCH POSITION MODE CONTINUITY BETWEEN
TURN SIGNAL IN NEUTRAL
HAZARD WARNING SWITCH OFF
HAZARD OFF
B-1 AND B-4
B-1 AND B-5
B-18 AND B-19
B-4 AND B-5
TURN SIGNAL ON
HAZARD WARNING SWITCH OFF
LEFT TURN
A-2 AND B-2
A-2 AND B-4
B-1 AND B-5
B-2 AND B-4
RIGHT TURN
A-2 AND B-5
B-1 AND B-4
B-5 AND B-6
TURN SIGNAL IN NEUTRAL
HAZARD WARNING SWITCH ON
HAZARD ON
A-2 AND B-2
A-2 AND B-4
A-2 AND B-5
A-2 AND B-6
A-3 AND A-5
A-3 AND B-7
B-2 AND B-4
B-2 AND B-5
B-2 AND B-6
B-4 AND B-5
B-4 AND B-6
B-5 AND B-6
PARK LAMP PARK B-9 AND B-20
HEADLAMP BEAM
LOW
B-16 AND B-18
B-16 AND B-19
B-9 AND B-20
B-1 AND B-4
HIGH
B-17 AND B-18
B-17 AND B-19
B-9 AND B-20
B-1 AND B-4
OPTICAL HORN
ON
B-17 AND B-18
B-17 AND B-19
FRONT FOG
ON
B-13 AND B-14
B-9 AND B-20
B-16 AND B-18
B-16 AND B-19
8L - 20 LAMPS ZB
MULTI-FUNCTION SWITCH (Continued)
