8W-91 CONNECTOR/GROUND/SPLICE LOCATION
TABLE OF CONTENTS
page
CONNECTOR/GROUND/SPLICE LOCATION
DESCRIPTION ..........................1
CONNECTOR/GROUND/SPLICE
LOCATION
DESCRIPTION
This section provides illustrations identifying con-
nector, ground and splice locations in the vehicle.
Connector, ground and splice indexes are provided.
Use the wiring diagrams in each section for connec-
tor, ground and splice identification. Refer to the
appropriate index for the proper figure number. For
items that are not shown in this section N/S is placed
in the Fig. column.
CONNECTORS
Connector Color Location Fig.
A/C Compressor Clutch BK Top of Compressor 1, 11
A/C-Heater Control C1 BK Rear of HVAC Control N/S
A/C-Heater Control C2 BK Rear of HVAC Control N/S
A/C Low Pressure Switch DK GN Right Rear Engine Compartment 5
A/C Pressure Transducer BK Left Front Engine Compartment 1, 2
Adjustable Pedals Motor WT Under Left Side of Instrument Panel N/S
Adjustable Pedals Switch WT Right Side of Steering Column 19
Airbag Control Module
(ORC) C1
YL Front of Center Console 19, 23
Airbag Control Module
(ORC) C2
YL Front of Center Console 19, 23
Airbag On/Off Switch - Pas-
senger
YL Rear of Center Console 23
Airbag Squib 1 - Driver YL/BK In Steering Wheel 21
Airbag Squib 2 - Driver YL/GY In Steering Wheel 21
Airbag Squib - Passenger YL Right Side of Instrument Panel 18
Ajar Switch - Decklid BK On Decklid 32
Ajar Switch - Driver Door BK Rear of Left Door 26
Ajar Switch - Hood NAT Right Rear of Engine Compartment 5
Ajar Switch - Passenger
Door
BK Rear of Passenger Door N/S
Amplifier Antenna NAT Behind Right Side of Instrument Panel 18
Back-Up Lamp Switch BR Right Side of Transmission 15
Back-Up Lamp - Left GY Left Rear Corner of Vehicle 31
Back-Up Lamp - Right GY Right Rear Corner of Vehicle 31
Battery Positive Post - Left Rear Trunk 28
Battery Temperature Sensor BK Rear of Battery 28, 29
ZB 8W-91 CONNECTOR/GROUND/SPLICE LOCATION 8W - 91 - 1
