The cover of the mechanical handle is only put loosely in place on delivery.
You must press the cover onto the assembly profile until it clicks audibly into
place.
Distortion of the cover possible due to forceful pressing.
Press the cover carefully until it clicks into the locking
points.
Use the heel of the hand to strike the outer edge of the
cover lightly if necessary.
Place the cover (1) over the lever handle as shown.
You must twist the cover when putting it in position if this is necessary.
Press the cover laterally onto the assembly profile (1.) until the locking
points of the cover (2) are in contact with the locking points of the assembly
profile (3) (1.).
Press the other side of the cover onto the assembly profile in such a way
that the locking points audibly click into place (2.).
The diagram which follows shows an example of the attachment.
Attach the other cover on the assembly profile in the same way.
