Place the cover over the lever handle.
You must twist the cover if this is necessary.
Place the cover (1) on the assembly profile from above first of all as shown.
Then press the cover onto the assembly profile from above and below (1.).
Ensure that the recess at the bottom of the cover is correctly positioned on
the cover closure.
Damage to the cover possible due to excessive tightening of
the screw.
Only tighten the screw (2) so that the plate of the cover
closure holds the cover securely.
Turn the screw (2) on the underside of the cover in an anticlockwise
direction to close the cover closure (2.).
The plate of the cover closure is pushed into the recess on the cover and it
locks the cover.
