Press the assembly profile of the inner lever handle rosette onto the door
leaf.
Insert the two long screws (2) through the guide slots on the assembly
profile (1) of the lever handle rosette into the drill holes as shown.
Screw the long screws into the threaded bushes so they are hand tight.
Check the lever handle for ease of movement.
Release the long screws a little if the lever handle does not move easily.
It is possible to damage the surface of the lever handle when
fitting the cover.
Do not use any force when installing the covers of handles.
Twist the cover round the lever handle while fitting in order
to avoid contact.
Ensure that the cover and the lever handle do not touch
when fitting the cover.
