Domino Gx-Series User Manual

Setting Name Explanation
Print start mode Select External if an external product detect sensor or an I/O input
is used to trigger each print.
Select Internal if an internal print trigger is used to trigger each
print.
Ensure this setting matches the print group's "Trigger by" setting,
see Print Trigger Setup on page 79.
Print speed mode Select External if an external shaft encoder or photocell encoder is
used to measure the production line/print speed.
Select Internal if an internal setting is used to measure/define the
production line/print speed.
Ensure this setting matches the print group's "Encoder input"
setting:
•
External shaft encoder, see External Shaft Encoder Setup/
Calibration on page 74.
• Internal encoder, see Internal Encoder Setup on page 75.
•
1 Photocell encoder, see 1 Photocell Encoder Setup on page
76.
•
2 Photocell encoder, see 2 Photocell Encoder Setup on page
77.
Name Displays the name of the label.
Message height (mm) Displays the print height of the label in millimetres.
Message width (mm) Define the print width of the label in millimetres.
Forward oset (mm) Define a space before the start of the label, to position the label on
the print surface.
Reverse oset (mm) Define a space after the end of the label, to position the label on
the print surface.
Delay after Input
Intell.Microp (mm)
Set a delay before the intelligent micro purge.
Production speed (m/min)
Note Only visible when Print speed mode is set to
Internal.
Set the print speed when Print speed mode is set to Internal.
Speed modification (%)
Note Only visible when Print speed mode is set to
External.
Shrink or stretch printing when Print speed mode is set to External.
Negative values shrink, positive values stretch.
OPERATION
135 EPT053091 - Issue 5 - 07 May 2021
