Domino Gx-Series

Setting Name Explanation
# of prints per object Define the number of print repetitions after one print trigger signal.
For example, if the value is set to 2:
Space between elements
of a message (mm)
Note Only visible when # of prints per object is set to a
value greater than 1.
Define the distance between print repetitions, if # of prints per
object is set to a value greater than 1.
Distance between prints
(mm)
Define the distance between groups of print repetitions, if # of
prints per object is set to a value greater than 1.
Print direction Define the print direction.
OPERATION
EPT053091 - Issue 5 - 07 May 2021 136
