2
CONTENTS
6.10 C-axis centerline and Y-axis movement squareness ....................................... 62
6.11 Table top and X-axis feed parallelism ........................................................... 66
6.12 Table top and Y-axis feed parallelism ........................................................... 68
6.13 Spindle centerline and Z-axis feed parallelism ............................................... 72
6.14 Run-Out of Spindle Cross Section ............................................................... 76
6.15 Run-Out of Spindle Internal Diameter ........................................................... 77
6.16 Run-Out of Table Top Surface .................................................................... 78
7. Adjustment of reference points of respective axes and manual TCP adjustment
....... 79
7.1 X- and Y-axis reference point resetting .......................................................... 79
7.2 Z-axis reference point resetting (Z-axis Stroke: 400mm) ................................... 81
7.3 B-axis reference point resetting (B-axis Stroke : B-30° ∼ B110°) ...................... 84
7.4 C-axis reference point resetting (C-axis Stroke : C0° ∼ C359.999°) .................. 85
7.5 DCP-i compensation .................................................................................... 86
8. ATC Alignment and Finishing Operation
................................................................ 92
8.1 Tool Change Position Resetting .................................................................... 93
8.2 Coolant Tank Installation .............................................................................. 96
8.3 Assembling the Covers ................................................................................ 98
