Dormakaba ED100LE - Connect Customer 115 Vac to Mounting Plate Terminal Block; Route Accessory Wiring to Mounting Plate

25
ED100LE 02-2021DL4616-001
dormakaba ED100LE operator – Fine cover
Installation Instructions
Chapter 8
.. Connect customer  Vac wiring.
WARNING
Work on electrical equipment and
EDLE  Vac wiring
installation must be only be
performed by qualified personnel!
WARNING
Insure disconnect supplying power
to EDLE operator is OFF
before connecting power!
. Route wiring to  Vac terminal block.
CAUTION
 Vac wiring.
Use copper conductors only!
. Connect  Vac wiring to terminal
block.
• Terminal block screw tightening torque.
CAUTION
TIGHTEN MAINS TERMINAL TO 5-7 in-lb
Use Copper Conductors ONLY
. Connect earth ground to ground post.
4 115 Vac terminal block
5 Ground post
Fig. 8.5.1 115 Vac wiring example
4
5
Fig. 8.6.1 Mounting plate slots for
accessory wiring
Fig. 8.5.2 Conduit box installation
. Connect customer  Vac to mounting plate terminal block
.. Route accessory wiring to mounting
plate.
. Route wiring to  Vac terminal block
side of mounting plate (Fig. ..).
. Accessory wiring opposite door hinge
side: route wiring into mounting plate
track (Fig. ..) to  Vac terminal
block side of mounting plate.
TIPS AND RECOMMENDATIONS
Accessory wiring will terminate at
EDLE terminal board (Chapter ).
. Route accessory wiring to mounting plate
Fig. 8.5.3 PC power cord, conduit box
installation
