dormakaba ED100 low energy operator – Fine cover
Installation Instructions
Appendix A
Fig. A.2.2 Mounting plates positioned for assembly
5
5
6
5 Mounting plate,
ED100LE operator
A.. Drill two holes in pair mounting plate for M
fastener.
. Drill hole in each end of pair mounting plate for
M x  mm PFHS (Fig. A..).
A.. Assemble mounting plates.
. Assemble the three mounting plates on a flat
surface (Fig. A..).
CAUTION
Verify mounting plate assembly dimensions with
installation template (Para. .).
6 Mounting plate, FC
extension
HC3468-010
Fig. A.2.3 Pair mounting plate hole for M6 fastener
2.5 mm tap drill
6
5
5 Mounting plate,
ED100LE operator
A.. Professional cover kit HK-X installation instructions – pair
2 Fine cover, pair,
HC3459-03X
3 End cap set,
HC3466-01X
4 Spindle cap set,
HC3466-02X
5 Backplate, ED
operator FC Ext
HC3468-010
7 Mounting extr
connector
HC3491-010
9 dormakaba
logoplate
HD4613-020
10 M6 x 10 mm SHS
with washer
HF3495-01Z
11 M6 x 10 mm PFHS,
HF3496-01Z
Fig. A.2.1 Fine cover kit, professional pair HK3401-07X
13 Logo placement
template
HP4613-001
17 Program switch,
3340 mm cable,
HX3486-030
18 Wire retainer
HX3493-010
6 Mounting plate, FC
extension
HC3468-010
2
4
17
7
10
11
9
5
18
13
3
