Dormakaba ED100LE - Install 8816 Closer on Backplate - Push Arm Mounting

45
ED100LE 02-2021DL4616-001
dormakaba ED100LE operator – Fine cover
Installation Instructions
Chapter 17
1 Backplate, ED
operator
companion
HC3468-050
2 Companion closer
adapter
HC3468-070
3 #4 x 1/4-20 x 5/8"
Philips flat head
screw
DF0399-00G
4 1/4-20 x 1" Philips
FHMS undercut
DF3101-01Z
5 Door closer, 8816
08210970
. Install  closer on backplate – push arm mounting
Fig. 17.2.3 Closer adapter and closer assembly mounting to backplate – push arm application
3 #4 x 1/4-20 x 5/8"
Philips flat head
screw
DF0399-00G
.. Install  closer for push arm application.
NOTICE
Verify closer spring size prior to installation.
NOTICE
PUSH (J) mounting holes.
For push arm application, use PUSH (J)
mounting holes (Fig.. 17.2.3).
(8) 4
Fig. 17.2.1 Companion screw kit
HK4607-001
(4) 3
Fig. 17.2.2 Companion closer
adapter fasteners
4 1/4-20 x 1" Philips
FHMS undercut
DF3101-01Z
1
2
5
(4) 3
(4) 4
PUSH (J)
PUSH (J)
PULL (T)
Fig. 17.2.4 Closer adapter and closer assembled to backplate
