46
ED100LE 02-2021DL4616-001
dormakaba ED100LE operator – Fine cover
Installation Instructions
Chapter 17
.. Push arm hardware.
. Reference Para. . for push arm
hardware.
.. Attach drive arm to closer.
CAUTION
Door must be fully closed!
WARNING
Use caution when working in
proximity of door and push arm!.
. Insert axle extension (Fig. ..) into
drive arm.
. Move arm to , inserting arm into
pinion at a angle.
. Insert M SHCS through drive arm and
axle extension. Thread SHCS into
pinion and tighten.
NOTICE
M8 SHCS tightening torque.
Use torque wrench (25 ft-lbs) to
tighten SHCS to 17 ft-lb [23 Nm].
. Push arm installation
Fig. 17.3.1 Drive arm installation
1 Drive arm
2 20 mm axle
extension
90°
1
2
3
3 20 mm bolt axle
extension
Fig. 17.3.2 Drive axle extensions
1 20 mm axle
extension, door
closer,
HC4680-001
2 60 mm axle
extension, door
closer,
HC4680-002
1
2
Fig. 17.3.4 Push arm screw kit
HK2719-010
1 10-24 x 1 1/2" pan
head Philips
slotted barrel nut
DF2718-01Z
2 10-24 x 1/2 " pan
head Philips screw
DF3278-01Z
Fig. 17.3.3 Bolt, axle extensions
1 20 mm bolt,axle
extension
HF3465-020
2 60 mm bolt axle
extension
HF3465-040
1
2
1
2
