Dormakaba ED100LE - Appendix A - Fine Cover Professional Cover Kits; Professional Cover Kit HK3401-05 X Installation Instructions - Single Door

54
ED100LE 02-2021DL4616-001
dormakaba ED100 low energy operator – Fine cover
Installation Instructions
Appendix A
Appendix A - Fine cover professional cover kits
A. Professional cover kit HK-X installation instructions – single door
A.. Install EDLE mounting plate.
Mounting plate installation:
• Reference Chapter , Para. . Mounting
plate attachment to jamb or wall.
A.. Secure mounting plate extension to
door frame and/or wall.
. Align mounting plate extension with
mounting plate.
. Mark mounting plate extension hole
locations in frame and/or wall. Drill four
holes for selected fasteners.
CAUTION
Use fasteners provided with
EDLE. Ref. Chapter .
. Secure mounting plate extension to door
frame or wall.
A.. Mounting plate installation checks.
CAUTION
• Check level.
• Check spindle to hinge
centerline distance.
• Check alignment.
Fig. A.1.2 ED100LE mounting plate
1 Mounting plate
Fig. A.1.3 Mounting plate extension
Fig. A.1.4 Mounting plate extension installation
1
1
2
1 Mounting plate 2 Mounting plate
extension
2
2 Mounting plate
extension
HC3614-010
Fig.A1.1 Fine cover kit professional single HK3401-05X
1 Fine cover single
HC3459-01X
3 End cap set
HC3466-01X
4 Backplate,
ED oper FC Ext,
HC3468-010
6 Cover bracket
HC3481-010
7 Mtg, extr
connector
HC3491-010
9 dormakaba logo
plate HD4613-010
10 M6 x 10 mm SHS
with washer
DF3495-01Z
11 M6 x 10 mm PFHS,
HF3496-01Z
13 Logo placement
template
HP4613-001
14 Mode switches
with cable
HX3482-010
15 Wire retainer
HX3493-010
A1.1 Fine cover kit professional single, HK3401-05X.
1
6
15
14
3
4
7
10
11
9
13
